PtpSeq()

PtpSeq() 1:

Clamp locking only active with NC transformer axes

The use of a lock segment is only inserted with an NC transformer axis! For hydraulic axes, the normal clamping of the FB_PtpMotion class is used.

Instance type

Instance Name

Master

fbPtpSeq

Slaves

fbProvideLockSegment

State diagram:

PtpSeq() 2:

Requirements

Development environment

Target platform

PLC libraries to include

TwinCAT >= v3.1.4024.54 (recommended)
TwinCAT >= v3.1.4024.42 (required)

PC or CX (x64, x86)

Tc3_PlasticBaseApplication (>= v3.12.7.0)
