PtpSeq()

PtpSeq() 1:

Blowpin PTP variant only active for NC axes

fbSeqProvideClamping is only inserted when using an NC axis. For hydraulic axes, the normal clamping of the FB_PtpMotion class is used.

Instance type

Instance Name

Master

fbPtpSeq

Slaves

fbSeqProvideClamping

State diagram:

PtpSeq() 2:

Requirements

Development environment

Target platform

PLC libraries to include

TwinCAT v3.1.4024.42

PC or CX (x64, x86)

Tc3_PlasticBaseApplication (>= v3.12.5.4)
