RespSetChargingProfile

RespSetChargingProfile 1:

With this method, an OCPP client responds to a Set Charging Profile request from the corresponding OCPP server.

RespSetChargingProfile 2:

Syntax

METHOD RespSetChargingProfile : BOOL
VAR_INPUT
    hMessageId : T_OCPP_MessageId;
    eStatus    : E_OCPP1_ChargingProfileStatus;
END_VAR

RespSetChargingProfile 3: Return value

Name

Type

Description

RespSetChargingProfile

BOOL

The method returns the return value TRUE if the call was successful. A method call is also considered successfully completed in the event of an error.

RespSetChargingProfile 4: Inputs

Name

Type

Description

hMessageId

T_OCPP_MessageId

MessageId of the received message.

eStatus

E_OCPP1_ChargingProfileStatus

Response whether the Charge Point was able to implement the requested Charging Profile.

Possible errors are output at the outputs bError and hrErrorCode of the function block instance.
