TwinCAT database server codes
ErrorCode | ErrorName | ErrorDescription |
|---|---|---|
0 | InternalErrorCode_0 | No Error |
1 | InternalErrorCode_1 | NULL Values not allowed |
2 | InternalErrorCode_2 | FB_DBRead selected value is NULL |
3 | InternalErrorCode_3 | DBID is unknown |
4 | InternalErrorCode_4 | ADSDevID is unknown |
5 | InternalErrorCode_5 | No open database connection found for DBID: xy |
6 | InternalErrorCode_6 | No open ADS Device connection found for ADSDevID: xy |
7 | InternalErrorCode_7 | Init of AutoLog Groups failed |
8 | InternalErrorCode_8 | AutoLog could NOT be started. TwinCAT Database Server has no valid device state |
9 | InternalErrorCode_9 | Record select value return => Wrong Parametersize from ADS-Device |
10 | InternalErrorCode_10 | Invalid Parameter |
11 | InternalErrorCode_11 | Couldn’t find PLCDBWrite Value in list |
12 | InternalErrorCode_12 | No valid symbol TYPE |
13 | InternalErrorCode_13 | Invalid parameter size |
14 | InternalErrorCode_14 | Execution timeout |
15 | InternalErrorCode_15 | Database connection already open |
16 | InternalErrorCode_16 | Database connection not initialized |
1000 | InternalErrorCode_1000 | Unknown internal Error |
