Coordinate system for fixture adaptation (ACS)

Coordinate system for fixture adaptation

Selection

#ACS ON

ACS serves to compensate for slanting of the workpiece or of the workpiece pallet. ACS can be selected or cancelled independently of a CS.

Coordinate system for fixture adaptation (ACS) 1:
Figure 1-6: Selection of a coordinate system for fixture adaptation

Effectiveness

Active up to cancellation or up to the end of the program.

Zero and reference point offsets can be programmed in ACS. However, these are valid only up to cancellation of ACS and are not stored.

Cancelling

#ACS OFF
