Online contour visualization

Data reduction

In the mode "online contour visualization" a real decoding of the NC program is executed. To ensure a high-performance data transmitting, the output values are filtered.

Grid pattern

Dependent on the used motion block (linear/curved) the grid for the interpolation points can be parameterized by specifying a maximum grid point distance or by giving a maximum path error.
